Code: Select all

// This Pine Script™ code is subject to the terms of the Mozilla Public License 2.0 at https://mozilla.org/MPL/2.0/
// © ChartPrime

//@version=5
indicator("Trending RSI [ChartPrime]", max_bars_back = 5000, timeframe = "", timeframe_gaps = true)

// Declarations {

convolve(float[] weights, float[] kernel, int iterations)=>
    var float[] convolution = weights.copy()

    if iterations > 0
        if barstate.isfirst
            for iteration = 0 to iterations - 1
                float[] temp = array.new<float>()

                for i = 0 to convolution.size() + kernel.size() - 2
                    float sum = 0.0

                    for j = 0 to kernel.size() - 1
                        int index = i - j

                        if index >= 0 and index < convolution.size()
                            sum += convolution.get(index) * kernel.get(j)
                        else
                            continue

                    temp.push(sum)

                convolution := temp.copy()

    convolution

method truncate_weights(float[] weights, bool enable = true)=>
    if enable
        int max_idx = weights.indexof(weights.max())

        if max_idx > 0
            for i = 0 to weights.indexof(weights.max()) - 1
                weights.shift()
        else
            weights

    weights

binomia_ma(float source, int length, bool enable)=>
    float pre_filter = ta.sma(source, 2)
    float[] h = array.from(0.5, 0.5)
    float[] weights = convolve(h, h, length * 10 - 1).truncate_weights()

    if enable and not na(source)
        float sum = 0
        float weight = 0

        for i = 0 to math.min(weights.size() - 1, bar_index)
            float w = weights.get(i)
            weight += w
            sum += nz(pre_filter[i], nz(source[i])) * w

        sum/weight

    else
        float(na)

precalculate_phi_coefficients(simple int length, simple float phase)=>
    var float[] coefficients = array.new<float>(length)
    var float E = 0.0

    const float SQRT_PIx2  = math.sqrt(2.0 * math.pi)
    const float MULTIPLIER = -0.5 / 0.93
    var int   length_1 = length - 1
    var float length_2 = length * 0.52353
    if barstate.isfirst
        for int i=0 to length_1
            float alpha = (i + phase - length_2) * MULTIPLIER
            float  beta = 1.0 / (0.2316419 * math.abs(alpha) + 1.0)
            float   phi = (math.exp(math.pow(alpha, 2) * -0.5)
                          *-0.398942280) * beta *
                          ( 0.319381530  + beta *
                          (-0.356563782  + beta *
                          ( 1.781477937  + beta *
                          (-1.821255978  + beta
                          * 1.330274429)))) + 1.011
            if alpha < 0.0
                phi := 1.0 - phi
            float weight = phi / SQRT_PIx2
            E += weight
            coefficients.set(i, weight)
    [coefficients, E]

phi_smoother(series float source, series float[] coefficients, series float E, simple float hf_ratio = 0.5)=>
    float sma2 = source * math.min(math.max(0.5, hf_ratio), 1) + nz(source[1], source) * math.max(math.min(0.5, 1 - hf_ratio), 0)
    int length = coefficients.size()
    if length > 1
        float W = 0.0
        for int i=0 to length - 1
            float weight = coefficients.get(i)
            W  += weight * sma2[i]
        W / E
    else
        source

rma(float source = close, float length = 9)=>
    float alpha = 1 / length
    var float smoothed = na
    smoothed := alpha * source + (1 - alpha) * nz(smoothed[1])

rsi(float source, int length)=>
    float up = math.max(source - source[1], 0)
    float down = math.max(source[1] - source, 0)
    float rs = rma(up, length) / rma(down, length)
    float rsi = 100 - 100 / (1 + rs)
    rsi

reverse_rsi(series float source, simple int length, float value)=>
    float src = (source - ta.rma(source, length)) / (length / 2)
    float alpha = 1 / length
    float average_up_count = 0.0
    float average_down_count = 0.0

    average_up_count := src > src[1]
                                     ? alpha * (src - src[1]) + (1 - alpha) * nz(average_up_count[1], 1)
                                     : (1 - alpha) * nz(average_up_count[1], 1)

    average_down_count := src > src[1]
                                     ? (1 - alpha) * nz(average_down_count[1], 1)
                                     : alpha * (src[1] - src) + (1 - alpha) * nz(average_down_count[1], 1)

    float reversed_value = (length - 1) * (average_down_count * value / (100 - value) - average_up_count)
    float reverse_rsi = reversed_value >= 0 ? src + reversed_value : src + reversed_value * (100 - value) / value

// }

// Inputs {

const string group_1 = "Settings"
const string top_value_tip = "Pick what RSI value you want the top range to represent."
const string bottom_value_tip = "Pick what RSI value you want the bottom range to represent"

float source = input.source(close, "Source", group = group_1)
int length = input.int(14, "Length", minval = 1, group = group_1)
float top_value = input.float(70, "Top Range", minval = 50, maxval = 99, tooltip = top_value_tip, group = group_1)
float bottom_value = input.float(30, "Bottom Range", minval = 1, maxval = 50, tooltip = bottom_value_tip, group = group_1)
bool ma_enable = input.bool(false, "MA Length        ", inline = "MA", group = group_1)
int ma_length = input.int(30, "", minval = 0, maxval = 100, inline = "MA", group = group_1)

const string group_2 = "Smoothing"
const string smoothing_tip = "Adjusts the period of the filter."
const string speed_tip = "Adjusts the responsiveness of the filter."
const string hf_tip = "Adjusts the pre smoothing of the filter." + "\n" + "1 is no pre smoothing while 0.5 is maximum pre smoothing."

int left = input.int(15, "Look Left", minval = 1, tooltip = left_tip, group = group_3)
int right = input.int(15, "Look Right", minval = 1, tooltip = right_tip, group = group_3)
int lower_range = input.int(5, "Lower Range", minval = 1, tooltip = lower_range_tip, group = group_3)
int upper_range = input.int(60, "Upper Range", minval = 1, tooltip = upper_range_tip, group = group_3)
string divergence_label = input.string("Line", "Divergence Drawings", ["Line", "Label", "Line and Label"], group = group_3)
bool bullish_divergence = false // input.bool(false, "Enable Bullish Divergence", group = group_3)
bool bearish_divergence = false // input.bool(false, "Enable Bearish Divergence", group = group_3)

const string group_4 = "Color"
bool glow = false // input.bool(true, "Glow", group = group_4)
color rsi_color = input.color(#ffffff, "RSI", group = group_4)
color ma_color = input.color(#FFEE54, "MA Color", group = group_4)
color bg_color = input.color(#7E57C21A, "BG", group = group_4)
color top_color = input.color(#a222e283, "Upper Range", group = group_4)
color bottom_color = input.color(#e5b60c83, "Lower Range", group = group_4)
color center_bullish_up_color = input.color(#21a110, "Center", inline = "Center", group = group_4)
color center_bullish_down_color = input.color(#005e05, "", inline = "Center", group = group_4)
color center_bearish_up_color = input.color(#FCA0A9, "", inline = "Center", group = group_4)
color center_bearish_down_color = input.color(#FB3E38, "", inline = "Center", group = group_4)
color bullish_divergence_color = input.color(#00B374, "Bullish Divergence", group = group_4)
color bearish_divergence_color = input.color(#F03042, "Bearish Divergence", group = group_4)
color divergence_text_color = input.color(#FEFEFE, "Divergence Text", group = group_4)
color zero_line_color = input.color(#9E9E9E, "0 Line Color", group = group_4)

// }

// Calculations {

[smoothing_coefficients, smoothing_E] = precalculate_phi_coefficients(smoothing, smoothing_phase)
[boundary_coefficients, boundary_E] = precalculate_phi_coefficients(boundary_smoothing, boundary_smoothing_phase)

float top = phi_smoother(reverse_rsi(source, length, top_value), boundary_coefficients, boundary_E, boundary_hf)
float bottom = phi_smoother(reverse_rsi(source, length, bottom_value), boundary_coefficients, boundary_E, boundary_hf)
float center = phi_smoother(reverse_rsi(source, length, 50), smoothing_coefficients, smoothing_E, smoothing_hf)

float rsi = phi_smoother(reverse_rsi(source, length, rsi(source, length)), smoothing_coefficients, smoothing_E, smoothing_hf)
float ma = binomia_ma(rsi, ma_length, ma_enable)

float center_delta = center - center[1]

// }

// Color Calculations {

color center_color = center >= 0
                                 ? (center_delta > 0 ? center_bullish_up_color : center_bullish_down_color)
                                 : (center_delta > 0 ? center_bearish_up_color : center_bearish_down_color)

color top_glow_color_max = color.new(top_color, 80)
color bottom_glow_color_max = color.new(bottom_color, 80)
color top_glow_color_min = color.new(top_color, 100)
color bottom_glow_color_min = color.new(bottom_color, 100)

color zero_line_solid = color.new(zero_line_color, 80)
color zero_line_dashed = color.new(zero_line_color, 50)

// }

// Plotting {
plot(0, "0 Line", zero_line_solid, display = display.pane)
top_band = plot(top, "Upper Range", top_color)
bottom_band = plot(bottom, "Lower Range", bottom_color)
fill(top_band, bottom_band, bg_color, "RSI Background Fill")
plot(center, "Center", center_color,2)
plot(ma, "MA", ma_color, display = ma_enable ? display.all : display.pane)
plot(rsi, "RSI", rsi_color)
// }

Code: Select all

//@version=5
indicator("FluidTrades - SMC Lite ", overlay = true, max_labels_count = 500, max_boxes_count = 500, max_lines_count = 500, max_bars_back = 1000)

//
//SETTINGS
//

//      INDICATOR SETTINGS
swing_length = input.int(10, title = 'Swing High/Low Length', group = 'Settings', minval = 1, maxval = 50)
history_of_demand_to_keep = input.int(20, title = 'History To Keep', minval = 5, maxval = 50)
box_width = input.float(2.5, title = 'Supply/Demand Box Width', group = 'Settings', minval = 1, maxval = 10, step = 0.5)

//      INDICATOR VISUAL SETTINGS
show_zigzag = input.bool(false, title = 'Show Zig Zag', group = 'Visual Settings', inline = '1')
show_price_action_labels = input.bool(false, title = 'Show Price Action Labels', group = 'Visual Settings', inline = '2')

supply_color = input.color(color.new(#EDEDED,70), title = 'Supply', group = 'Visual Settings', inline = '3')
supply_outline_color = input.color(color.new(color.white,75), title = 'Outline', group = 'Visual Settings', inline = '3')

demand_color = input.color(color.new(#00FFFF,70), title = 'Demand', group = 'Visual Settings', inline = '4')
demand_outline_color = input.color(color.new(color.white,75), title = 'Outline', group = 'Visual Settings', inline = '4')

bos_label_color = input.color(color.white, title = 'BOS Label', group = 'Visual Settings', inline = '5')
poi_label_color = input.color(color.white, title = 'POI Label', group = 'Visual Settings', inline = '7')

swing_type_color = input.color(color.black, title = 'Price Action Label', group = 'Visual Settings', inline = '8')
zigzag_color = input.color(color.new(#000000,0), title = 'Zig Zag', group = 'Visual Settings', inline = '9')

//
//END SETTINGS
//


//
//FUNCTIONS
//

//      FUNCTION TO ADD NEW AND REMOVE LAST IN ARRAY
f_array_add_pop(array, new_value_to_add) =>
    array.unshift(array, new_value_to_add)
    array.pop(array)

//      FUNCTION SWING H & L LABELS
f_sh_sl_labels(array, swing_type) =>

    var string label_text = na
    if swing_type == 1
        if array.get(array, 0) >= array.get(array, 1)
            label_text := 'HH'
        else
            label_text := 'LH'
        label.new(bar_index - swing_length, array.get(array,0), text = label_text, style=label.style_label_down, textcolor = swing_type_color, color = color.new(swing_type_color, 100), size = size.tiny)

    else if swing_type == -1
        if array.get(array, 0) >= array.get(array, 1)
            label_text := 'HL'
        else
            label_text := 'LL'
        label.new(bar_index - swing_length, array.get(array,0), text = label_text, style=label.style_label_up, textcolor = swing_type_color, color = color.new(swing_type_color, 100), size = size.tiny)

//      FUNCTION MAKE SURE SUPPLY ISNT OVERLAPPING
f_check_overlapping(new_poi, box_array, atr) =>

    atr_threshold = atr * 2
    okay_to_draw = true

    for i = 0 to array.size(box_array) - 1
        top = box.get_top(array.get(box_array, i))
        bottom = box.get_bottom(array.get(box_array, i))
        poi = (top + bottom) / 2

        upper_boundary = poi + atr_threshold
        lower_boundary = poi - atr_threshold

        if new_poi >= lower_boundary and new_poi <= upper_boundary
            okay_to_draw := false
            break
        else
            okay_to_draw := true
    okay_to_draw


//      FUNCTION TO DRAW SUPPLY OR DEMAND ZONE
f_supply_demand(value_array, bn_array, box_array, label_array, box_type, atr) =>

    atr_buffer = atr * (box_width / 10)
    box_left = array.get(bn_array, 0)
    box_right = bar_index

    var float box_top = 0.00
    var float box_bottom = 0.00
    var float poi = 0.00


    if box_type == 1
        box_top := array.get(value_array, 0)
        box_bottom := box_top - atr_buffer
        poi := (box_top + box_bottom) / 2
    else if box_type == -1
        box_bottom := array.get(value_array, 0)
        box_top := box_bottom + atr_buffer
        poi := (box_top + box_bottom) / 2

    okay_to_draw = f_check_overlapping(poi, box_array, atr)
    // okay_to_draw = true

    //delete oldest box, and then create a new box and add it to the array
    if box_type == 1 and okay_to_draw
        box.delete( array.get(box_array, array.size(box_array) - 1) )
        f_array_add_pop(box_array, box.new( left = box_left, top = box_top, right = box_right, bottom = box_bottom, border_color = supply_outline_color,
             bgcolor = supply_color, extend = extend.right, text = 'SUPPLY', text_halign = text.align_center, text_valign = text.align_center, text_color = poi_label_color, text_size = size.small, xloc = xloc.bar_index))

        box.delete( array.get(label_array, array.size(label_array) - 1) )
        f_array_add_pop(label_array, box.new( left = box_left, top = poi, right = box_right, bottom = poi, border_color = color.new(poi_label_color,90),
             bgcolor = color.new(poi_label_color,90), extend = extend.right, text = 'POI', text_halign = text.align_left, text_valign = text.align_center, text_color = poi_label_color, text_size = size.small, xloc = xloc.bar_index))

    else if box_type == -1 and okay_to_draw
        box.delete( array.get(box_array, array.size(box_array) - 1) )
        f_array_add_pop(box_array, box.new( left = box_left, top = box_top, right = box_right, bottom = box_bottom, border_color = demand_outline_color,
             bgcolor = demand_color, extend = extend.right,  text = 'DEMAND', text_halign = text.align_center, text_valign = text.align_center, text_color = poi_label_color, text_size = size.small, xloc = xloc.bar_index))

        box.delete( array.get(label_array, array.size(label_array) - 1) )
        f_array_add_pop(label_array, box.new( left = box_left, top = poi, right = box_right, bottom = poi, border_color = color.new(poi_label_color,90),
             bgcolor = color.new(poi_label_color,90), extend = extend.right,  text = 'POI', text_halign = text.align_left, text_valign = text.align_center, text_color = poi_label_color, text_size = size.small, xloc = xloc.bar_index))


//      FUNCTION TO CHANGE SUPPLY/DEMAND TO A BOS IF BROKEN
f_sd_to_bos(box_array, bos_array, label_array, zone_type) =>

    if zone_type == 1
        for i = 0 to array.size(box_array) - 1
            level_to_break = box.get_top(array.get(box_array,i))
            // if ta.crossover(close, level_to_break)
            if close >= level_to_break
                copied_box = box.copy(array.get(box_array,i))
                f_array_add_pop(bos_array, copied_box)
                mid = (box.get_top(array.get(box_array,i)) + box.get_bottom(array.get(box_array,i))) / 2
                box.set_top(array.get(bos_array,0), mid)
                box.set_bottom(array.get(bos_array,0), mid)
                box.set_extend( array.get(bos_array,0), extend.none)
                box.set_right( array.get(bos_array,0), bar_index)
                box.set_text( array.get(bos_array,0), 'BOS' )
                box.set_text_color( array.get(bos_array,0), bos_label_color)
                box.set_text_size( array.get(bos_array,0), size.small)
                box.set_text_halign( array.get(bos_array,0), text.align_center)
                box.set_text_valign( array.get(bos_array,0), text.align_center)
                box.delete(array.get(box_array, i))
                box.delete(array.get(label_array, i))


    if zone_type == -1
        for i = 0 to array.size(box_array) - 1
            level_to_break = box.get_bottom(array.get(box_array,i))
            // if ta.crossunder(close, level_to_break)
            if close <= level_to_break
                copied_box = box.copy(array.get(box_array,i))
                f_array_add_pop(bos_array, copied_box)
                mid = (box.get_top(array.get(box_array,i)) + box.get_bottom(array.get(box_array,i))) / 2
                box.set_top(array.get(bos_array,0), mid)
                box.set_bottom(array.get(bos_array,0), mid)
                box.set_extend( array.get(bos_array,0), extend.none)
                box.set_right( array.get(bos_array,0), bar_index)
                box.set_text( array.get(bos_array,0), 'BOS' )
                box.set_text_color( array.get(bos_array,0), bos_label_color)
                box.set_text_size( array.get(bos_array,0), size.small)
                box.set_text_halign( array.get(bos_array,0), text.align_center)
                box.set_text_valign( array.get(bos_array,0), text.align_center)
                box.delete(array.get(box_array, i))
                box.delete(array.get(label_array, i))



//      FUNCTION MANAGE CURRENT BOXES BY CHANGING ENDPOINT
f_extend_box_endpoint(box_array) =>

    for i = 0 to array.size(box_array) - 1
        box.set_right(array.get(box_array, i), bar_index + 100)


//
//END FUNCTIONS
//


//
//CALCULATIONS
//

//      CALCULATE ATR
atr = ta.atr(50)

//      CALCULATE SWING HIGHS & SWING LOWS
swing_high = ta.pivothigh(high, swing_length, swing_length)
swing_low = ta.pivotlow(low, swing_length, swing_length)

//      ARRAYS FOR SWING H/L & BN
var swing_high_values = array.new_float(5,0.00)
var swing_low_values = array.new_float(5,0.00)

var swing_high_bns = array.new_int(5,0)
var swing_low_bns = array.new_int(5,0)

//      ARRAYS FOR SUPPLY / DEMAND
var current_supply_box = array.new_box(history_of_demand_to_keep, na)
var current_demand_box = array.new_box(history_of_demand_to_keep, na)

//      ARRAYS FOR SUPPLY / DEMAND POI LABELS
var current_supply_poi = array.new_box(history_of_demand_to_keep, na)
var current_demand_poi = array.new_box(history_of_demand_to_keep, na)

//      ARRAYS FOR BOS
var supply_bos = array.new_box(5, na)
var demand_bos = array.new_box(5, na)
//
//END CALCULATIONS
//

//      NEW SWING HIGH
if not na(swing_high)

    //MANAGE SWING HIGH VALUES
    f_array_add_pop(swing_high_values, swing_high)
    f_array_add_pop(swing_high_bns, bar_index[swing_length])
    if show_price_action_labels
        f_sh_sl_labels(swing_high_values, 1)

    f_supply_demand(swing_high_values, swing_high_bns, current_supply_box, current_supply_poi, 1, atr)

//      NEW SWING LOW
else if not na(swing_low)

    //MANAGE SWING LOW VALUES
    f_array_add_pop(swing_low_values, swing_low)
    f_array_add_pop(swing_low_bns, bar_index[swing_length])
    if show_price_action_labels
        f_sh_sl_labels(swing_low_values, -1)

    f_supply_demand(swing_low_values, swing_low_bns, current_demand_box, current_demand_poi, -1, atr)


f_sd_to_bos(current_supply_box, supply_bos, current_supply_poi, 1)
f_sd_to_bos(current_demand_box, demand_bos, current_demand_poi, -1)

f_extend_box_endpoint(current_supply_box)
f_extend_box_endpoint(current_demand_box)

//ZIG ZAG
h = ta.highest(high, swing_length * 2 + 1)
l = ta.lowest(low, swing_length * 2 + 1)
f_isMin(len) =>
    l == low[len]
f_isMax(len) =>
    h == high[len]

var dirUp = false
var lastLow = high * 100
var lastHigh = 0.0
var timeLow = bar_index
var timeHigh = bar_index
var line li = na

f_drawLine() =>
    _li_color = show_zigzag ? zigzag_color : color.new(#ffffff,100)
    line.new(timeHigh - swing_length, lastHigh, timeLow - swing_length, lastLow, xloc.bar_index, color=_li_color, width=2)

if dirUp
    if f_isMin(swing_length) and low[swing_length] < lastLow
        lastLow := low[swing_length]
        timeLow := bar_index
        line.delete(li)
        li := f_drawLine()
        li

    if f_isMax(swing_length) and high[swing_length] > lastLow
        lastHigh := high[swing_length]
        timeHigh := bar_index
        dirUp := false
        li := f_drawLine()
        li

if not dirUp
    if f_isMax(swing_length) and high[swing_length] > lastHigh
        lastHigh := high[swing_length]
        timeHigh := bar_index
        line.delete(li)
        li := f_drawLine()
        li
    if f_isMin(swing_length) and low[swing_length] < lastHigh
        lastLow := low[swing_length]
        timeLow := bar_index
        dirUp := true
        li := f_drawLine()
        if f_isMax(swing_length) and high[swing_length] > lastLow
            lastHigh := high[swing_length]
            timeHigh := bar_index
            dirUp := false
            li := f_drawLine()
            li
// if barstate.islast
    // label.new(x = bar_index + 10, y = close[1], text = str.tostring( array.size(current_supply_poi) ))
//     label.new(x = bar_index + 20, y = close[1], text = str.tostring( box.get_bottom( array.get(current_supply_box, 0))))
//     label.new(x = bar_index + 30, y = close[1], text = str.tostring( box.get_bottom( array.get(current_supply_box, 1))))
//     label.new(x = bar_index + 40, y = close[1], text = str.tostring( box.get_bottom( array.get(current_supply_box, 2))))
//     label.new(x = bar_index + 50, y = close[1], text = str.tostring( box.get_bottom( array.get(current_supply_box, 3))))
//     label.new(x = bar_index + 60, y = close[1], text = str.tostring( box.get_bottom( array.get(current_supply_box, 4))))

Code: Select all

//@version=5
indicator("Smart Money Concepts [LuxAlgo]", "Smart Money Concepts [LuxAlgo]"
  , overlay = true
  , max_labels_count = 500
  , max_lines_count = 500
  , max_boxes_count = 500
  , max_bars_back = 500)
//-----------------------------------------------------------------------------{
//Constants
//-----------------------------------------------------------------------------{
color TRANSP_CSS = #ffffff00

//Tooltips
string MODE_TOOLTIP          = 'Allows to display historical Structure or only the recent ones'
string STYLE_TOOLTIP         = 'Indicator color theme'
string COLOR_CANDLES_TOOLTIP = 'Display additional candles with a color reflecting the current trend detected by structure'
string SHOW_INTERNAL         = 'Display internal market structure'
string CONFLUENCE_FILTER     = 'Filter non significant internal structure breakouts'
string SHOW_SWING            = 'Display swing market Structure'
string SHOW_SWING_POINTS     = 'Display swing point as labels on the chart'
string SHOW_SWHL_POINTS      = 'Highlight most recent strong and weak high/low points on the chart'
string INTERNAL_OB           = 'Display internal order blocks on the chart\n\nNumber of internal order blocks to display on the chart'
string SWING_OB              = 'Display swing order blocks on the chart\n\nNumber of internal swing blocks to display on the chart'
string FILTER_OB             = 'Method used to filter out volatile order blocks \n\nIt is recommended to use the cumulative mean range method when a low amount of data is available'
string SHOW_EQHL             = 'Display equal highs and equal lows on the chart'
string EQHL_BARS             = 'Number of bars used to confirm equal highs and equal lows'
string EQHL_THRESHOLD        = 'Sensitivity threshold in a range (0, 1) used for the detection of equal highs & lows\n\nLower values will return fewer but more pertinent results'
string SHOW_FVG              = 'Display fair values gaps on the chart'
string AUTO_FVG              = 'Filter out non significant fair value gaps'
string FVG_TF                = 'Fair value gaps timeframe'
string EXTEND_FVG            = 'Determine how many bars to extend the Fair Value Gap boxes on chart'
string PED_ZONES             = 'Display premium, discount, and equilibrium zones on chart'

//-----------------------------------------------------------------------------{
//Settings
//-----------------------------------------------------------------------------{
//General
//----------------------------------------{
mode = input.string('Historical'
  , options = ['Historical', 'Present']
  , group = 'Smart Money Concepts'
  , tooltip = MODE_TOOLTIP)

style = input.string('Colored'
  , options = ['Colored', 'Monochrome']
  , group = 'Smart Money Concepts'
  , tooltip = STYLE_TOOLTIP)

show_trend = input(false, 'Color Candles'
  , group = 'Smart Money Concepts'
  , tooltip = COLOR_CANDLES_TOOLTIP)

//----------------------------------------}
//Internal Structure
//----------------------------------------{
show_internals = input(true, 'Show Internal Structure'
  , group = 'Real Time Internal Structure'
  , tooltip = SHOW_INTERNAL)

show_ibull = input.string('All', 'Bullish Structure'
  , options = ['All', 'BOS', 'CHoCH']
  , inline = 'ibull'
  , group = 'Real Time Internal Structure')

swing_ibull_css = input(#089981, ''
  , inline = 'ibull'
  , group = 'Real Time Internal Structure')

//Bear Structure
show_ibear = input.string('All', 'Bearish Structure'
  , options = ['All', 'BOS', 'CHoCH']
  , inline = 'ibear'
  , group = 'Real Time Internal Structure')

swing_ibear_css = input(#f23645, ''
  , inline = 'ibear'
  , group = 'Real Time Internal Structure')

ifilter_confluence = input(false, 'Confluence Filter'
  , group = 'Real Time Internal Structure'
  , tooltip = CONFLUENCE_FILTER)

internal_structure_size = input.string('Tiny', 'Internal Label Size'
  , options = ['Tiny', 'Small', 'Normal']
  , group = 'Real Time Internal Structure')

//----------------------------------------}
//Swing Structure
//----------------------------------------{
show_Structure = input(true, 'Show Swing Structure'
  , group = 'Real Time Swing Structure'
  , tooltip = SHOW_SWING)

//Bull Structure
show_bull = input.string('All', 'Bullish Structure'
  , options = ['All', 'BOS', 'CHoCH']
  , inline = 'bull'
  , group = 'Real Time Swing Structure')

swing_bull_css = input(#089981, ''
  , inline = 'bull'
  , group = 'Real Time Swing Structure')

//Bear Structure
show_bear = input.string('All', 'Bearish Structure'
  , options = ['All', 'BOS', 'CHoCH']
  , inline = 'bear'
  , group = 'Real Time Swing Structure')

swing_bear_css = input(#f23645, ''
  , inline = 'bear'
  , group = 'Real Time Swing Structure')

swing_structure_size = input.string('Small', 'Swing Label Size'
  , options = ['Tiny', 'Small', 'Normal']
  , group = 'Real Time Swing Structure')

//Swings
show_swings = input(false, 'Show Swings Points'
  , inline = 'swings'
  , group = 'Real Time Swing Structure'
  , tooltip = SHOW_SWING_POINTS)

length = input.int(50, ''
  , minval = 10
  , inline = 'swings'
  , group = 'Real Time Swing Structure')

show_hl_swings = input(true, 'Show Strong/Weak High/Low'
  , group = 'Real Time Swing Structure'
  , tooltip = SHOW_SWHL_POINTS)

//----------------------------------------}
//Order Blocks
//----------------------------------------{
show_iob = input(true, 'Internal Order Blocks'
  , inline = 'iob'
  , group = 'Order Blocks'
  , tooltip = INTERNAL_OB)

iob_showlast = input.int(5, ''
  , minval = 1
  , inline = 'iob'
  , group = 'Order Blocks')

show_ob = input(false, 'Swing Order Blocks'
  , inline = 'ob'
  , group = 'Order Blocks'
  , tooltip = SWING_OB)

ob_showlast = input.int(5, ''
  , minval = 1
  , inline = 'ob'
  , group = 'Order Blocks')

ob_filter = input.string('Atr', 'Order Block Filter'
  , options = ['Atr', 'Cumulative Mean Range']
  , group = 'Order Blocks'
  , tooltip = FILTER_OB)

ibull_ob_css = input.color(color.new(#3179f5, 80), 'Internal Bullish OB'
  , group = 'Order Blocks')

ibear_ob_css = input.color(color.new(#f77c80, 80), 'Internal Bearish OB'
  , group = 'Order Blocks')

bull_ob_css = input.color(color.new(#1848cc, 80), 'Bullish OB'
  , group = 'Order Blocks')

bear_ob_css = input.color(color.new(#b22833, 80), 'Bearish OB'
  , group = 'Order Blocks')

//----------------------------------------}
//EQH/EQL
//----------------------------------------{
show_eq = input(true, 'Equal High/Low'
  , group = 'EQH/EQL'
  , tooltip = SHOW_EQHL)

eq_len = input.int(3, 'Bars Confirmation'
  , minval = 1
  , group = 'EQH/EQL'
  , tooltip = EQHL_BARS)

eq_threshold = input.float(0.1, 'Threshold'
  , minval = 0
  , maxval = 0.5
  , step = 0.1
  , group = 'EQH/EQL'
  , tooltip = EQHL_THRESHOLD)

eq_size = input.string('Tiny', 'Label Size'
  , options = ['Tiny', 'Small', 'Normal']
  , group = 'EQH/EQL')

//----------------------------------------}
//Fair Value Gaps
//----------------------------------------{
show_fvg = input(false, 'Fair Value Gaps'
  , group = 'Fair Value Gaps'
  , tooltip = SHOW_FVG)

fvg_auto = input(true, "Auto Threshold"
  , group = 'Fair Value Gaps'
  , tooltip = AUTO_FVG)

fvg_tf = input.timeframe('', "Timeframe"
  , group = 'Fair Value Gaps'
  , tooltip = FVG_TF)

bull_fvg_css = input.color(color.new(#00ff68, 70), 'Bullish FVG'
  , group = 'Fair Value Gaps')

bear_fvg_css = input.color(color.new(#ff0008, 70), 'Bearish FVG'
  , group = 'Fair Value Gaps')

fvg_extend = input.int(1, "Extend FVG"
  , minval = 0
  , group = 'Fair Value Gaps'
  , tooltip = EXTEND_FVG)

//----------------------------------------}
//Previous day/week high/low
//----------------------------------------{
//Daily
show_pdhl = input(false, 'Daily'
  , inline = 'daily'
  , group = 'Highs & Lows MTF')

pdhl_style = input.string('⎯⎯⎯', ''
  , options = ['⎯⎯⎯', '----', '····']
  , inline = 'daily'
  , group = 'Highs & Lows MTF')

pdhl_css = input(#2157f3, ''
  , inline = 'daily'
  , group = 'Highs & Lows MTF')

//Weekly
show_pwhl = input(false, 'Weekly'
  , inline = 'weekly'
  , group = 'Highs & Lows MTF')

pwhl_style = input.string('⎯⎯⎯', ''
  , options = ['⎯⎯⎯', '----', '····']
  , inline = 'weekly'
  , group = 'Highs & Lows MTF')

pwhl_css = input(#2157f3, ''
  , inline = 'weekly'
  , group = 'Highs & Lows MTF')

//Monthly
show_pmhl = input(false, 'Monthly'
  , inline = 'monthly'
  , group = 'Highs & Lows MTF')

pmhl_style = input.string('⎯⎯⎯', ''
  , options = ['⎯⎯⎯', '----', '····']
  , inline = 'monthly'
  , group = 'Highs & Lows MTF')

pmhl_css = input(#2157f3, ''
  , inline = 'monthly'
  , group = 'Highs & Lows MTF')

//----------------------------------------}
//Premium/Discount zones
//----------------------------------------{
show_sd = input(false, 'Premium/Discount Zones'
  , group = 'Premium & Discount Zones'
  , tooltip = PED_ZONES)

premium_css = input.color(#f23645, 'Premium Zone'
  , group = 'Premium & Discount Zones')

eq_css = input.color(#b2b5be, 'Equilibrium Zone'
  , group = 'Premium & Discount Zones')

discount_css = input.color(#089981, 'Discount Zone'
  , group = 'Premium & Discount Zones')

//-----------------------------------------------------------------------------}
//Functions
//-----------------------------------------------------------------------------{
n = bar_index

atr = ta.atr(200)
cmean_range = ta.cum(high - low) / n

//HL Output function
hl() => [high, low]

//Get ohlc values function
get_ohlc()=> [close[1], open[1], high, low, high[2], low[2]]

//Display Structure function
display_Structure(x, y, txt, css, dashed, down, lbl_size)=>
    structure_line = line.new(x, y, n, y
      , color = css
      , style = dashed ? line.style_dashed : line.style_solid)

    structure_lbl = label.new(int(math.avg(x, n)), y, txt
      , color = TRANSP_CSS
      , textcolor = css
      , style = down ? label.style_label_down : label.style_label_up
      , size = lbl_size)

    if mode == 'Present'
        line.delete(structure_line[1])
        label.delete(structure_lbl[1])

//Swings detection/measurements
swings(len)=>
    var os = 0

    upper = ta.highest(len)
    lower = ta.lowest(len)

    os := high[len] > upper ? 0 : low[len] < lower ? 1 : os[1]

    top = os == 0 and os[1] != 0 ? high[len] : 0
    btm = os == 1 and os[1] != 1 ? low[len] : 0

    [top, btm]

//Order block coordinates function
ob_coord(use_max, loc, target_top, target_btm, target_left, target_type)=>
    min = 99999999.
    max = 0.
    idx = 1

    ob_threshold = ob_filter == 'Atr' ? atr : cmean_range

    //Search for highest/lowest high within the structure interval and get range
    if use_max
        for i = 1 to (n - loc)-1
            if (high[i] - low[i]) < ob_threshold[i] * 2
                max := math.max(high[i], max)
                min := max == high[i] ? low[i] : min
                idx := max == high[i] ? i : idx
    else
        for i = 1 to (n - loc)-1
            if (high[i] - low[i]) < ob_threshold[i] * 2
                min := math.min(low[i], min)
                max := min == low[i] ? high[i] : max
                idx := min == low[i] ? i : idx

    array.unshift(target_top, max)
    array.unshift(target_btm, min)
    array.unshift(target_left, time[idx])
    array.unshift(target_type, use_max ? -1 : 1)

//Set order blocks
display_ob(boxes, target_top, target_btm, target_left, target_type, show_last, swing, size)=>
    for i = 0 to math.min(show_last-1, size-1)
        get_box = array.get(boxes, i)

        box.set_lefttop(get_box, array.get(target_left, i), array.get(target_top, i))
        box.set_rightbottom(get_box, array.get(target_left, i), array.get(target_btm, i))
        box.set_extend(get_box, extend.right)

        color css = na

        if swing
            if style == 'Monochrome'
                css := array.get(target_type, i) == 1 ? color.new(#b2b5be, 80) : color.new(#5d606b, 80)
                border_css = array.get(target_type, i) == 1 ? #b2b5be : #5d606b
                box.set_border_color(get_box, border_css)
            else
                css := array.get(target_type, i) == 1 ? bull_ob_css : bear_ob_css
                box.set_border_color(get_box, css)

            box.set_bgcolor(get_box, css)
        else
            if style == 'Monochrome'
                css := array.get(target_type, i) == 1 ? color.new(#b2b5be, 80) : color.new(#5d606b, 80)
            else
                css := array.get(target_type, i) == 1 ? ibull_ob_css : ibear_ob_css

            box.set_border_color(get_box, css)
            box.set_bgcolor(get_box, css)

//Line Style function
get_line_style(style) =>
    out = switch style
        '⎯⎯⎯'  => line.style_solid
        '----' => line.style_dashed
        '····' => line.style_dotted

//Set line/labels function for previous high/lows
phl(h, l, tf, css)=>
    var line high_line = line.new(na,na,na,na
      , xloc = xloc.bar_time
      , color = css
      , style = get_line_style(pdhl_style))

    var label high_lbl = label.new(na,na
      , xloc = xloc.bar_time
      , text = str.format('P{0}H', tf)
      , color = TRANSP_CSS
      , textcolor = css
      , size = size.small
      , style = label.style_label_left)

    var line low_line = line.new(na,na,na,na
      , xloc = xloc.bar_time
      , color = css
      , style = get_line_style(pdhl_style))

    var label low_lbl = label.new(na,na
      , xloc = xloc.bar_time
      , text = str.format('P{0}L', tf)
      , color = TRANSP_CSS
      , textcolor = css
      , size = size.small
      , style = label.style_label_left)

    hy = ta.valuewhen(h != h[1], h, 1)
    hx = ta.valuewhen(h == high, time, 1)

    ly = ta.valuewhen(l != l[1], l, 1)
    lx = ta.valuewhen(l == low, time, 1)

    if barstate.islast
        ext = time + (time - time[1])*20

        //High
        line.set_xy1(high_line, hx, hy)
        line.set_xy2(high_line, ext, hy)

        label.set_xy(high_lbl, ext, hy)

        //Low
        line.set_xy1(low_line, lx, ly)
        line.set_xy2(low_line, ext, ly)

        label.set_xy(low_lbl, ext, ly)

//-----------------------------------------------------------------------------}
//Global variables
//-----------------------------------------------------------------------------{
var trend = 0, var itrend = 0

var top_y = 0., var top_x = 0
var btm_y = 0., var btm_x = 0

var itop_y = 0., var itop_x = 0
var ibtm_y = 0., var ibtm_x = 0

var trail_up = high, var trail_dn = low
var trail_up_x = 0,  var trail_dn_x = 0

var top_cross = true,  var btm_cross = true
var itop_cross = true, var ibtm_cross = true

var txt_top = '',  var txt_btm = ''

//Alerts
bull_choch_alert = false
bull_bos_alert   = false

bear_choch_alert = false
bear_bos_alert   = false

bull_ichoch_alert = false
bull_ibos_alert   = false

bear_ichoch_alert = false
bear_ibos_alert   = false

bull_iob_break = false
bear_iob_break = false

bull_ob_break = false
bear_ob_break = false

eqh_alert = false
eql_alert = false

//Structure colors
var bull_css = style == 'Monochrome' ? #b2b5be
  : swing_bull_css

var bear_css = style == 'Monochrome' ? #b2b5be
  : swing_bear_css

var ibull_css = style == 'Monochrome' ? #b2b5be
  : swing_ibull_css

var ibear_css = style == 'Monochrome' ? #b2b5be
  : swing_ibear_css

//Labels size
var internal_structure_lbl_size = internal_structure_size == 'Tiny'
  ? size.tiny
  : internal_structure_size == 'Small'
  ? size.small
  : size.normal

var swing_structure_lbl_size = swing_structure_size == 'Tiny'
  ? size.tiny
  : swing_structure_size == 'Small'
  ? size.small
  : size.normal

var eqhl_lbl_size = eq_size == 'Tiny'
  ? size.tiny
  : eq_size == 'Small'
  ? size.small
  : size.normal

//Swings
[top, btm] = swings(length)

[itop, ibtm] = swings(5)

//-----------------------------------------------------------------------------}
//Pivot High
//-----------------------------------------------------------------------------{
var line extend_top = na

var label extend_top_lbl = label.new(na, na
  , color = TRANSP_CSS
  , textcolor = bear_css
  , style = label.style_label_down
  , size = size.tiny)

if top
    top_cross := true
    txt_top := top > top_y ? 'HH' : 'LH'

    if show_swings
        top_lbl = label.new(n-length, top, txt_top
          , color = TRANSP_CSS
          , textcolor = bear_css
          , style = label.style_label_down
          , size = swing_structure_lbl_size)

        if mode == 'Present'
            label.delete(top_lbl[1])

    //Extend recent top to last bar
    line.delete(extend_top[1])
    extend_top := line.new(n-length, top, n, top
      , color = bear_css)

    top_y := top
    top_x := n - length

    trail_up := top
    trail_up_x := n - length

if itop
    itop_cross := true

    itop_y := itop
    itop_x := n - 5

//Trailing maximum
trail_up := math.max(high, trail_up)
trail_up_x := trail_up == high ? n : trail_up_x

//Set top extension label/line
if barstate.islast and show_hl_swings
    line.set_xy1(extend_top, trail_up_x, trail_up)
    line.set_xy2(extend_top, n + 20, trail_up)

    label.set_x(extend_top_lbl, n + 20)
    label.set_y(extend_top_lbl, trail_up)
    label.set_text(extend_top_lbl, trend < 0 ? 'Strong High' : 'Weak High')

//-----------------------------------------------------------------------------}
//Pivot Low
//-----------------------------------------------------------------------------{
var line extend_btm = na

var label extend_btm_lbl = label.new(na, na
  , color = TRANSP_CSS
  , textcolor = bull_css
  , style = label.style_label_up
  , size = size.tiny)

if btm
    btm_cross := true
    txt_btm := btm < btm_y ? 'LL' : 'HL'

    if show_swings
        btm_lbl = label.new(n - length, btm, txt_btm
          , color = TRANSP_CSS
          , textcolor = bull_css
          , style = label.style_label_up
          , size = swing_structure_lbl_size)

        if mode == 'Present'
            label.delete(btm_lbl[1])

    //Extend recent btm to last bar
    line.delete(extend_btm[1])
    extend_btm := line.new(n - length, btm, n, btm
      , color = bull_css)

    btm_y := btm
    btm_x := n-length

    trail_dn := btm
    trail_dn_x := n-length

if ibtm
    ibtm_cross := true

    ibtm_y := ibtm
    ibtm_x := n - 5

//Trailing minimum
trail_dn := math.min(low, trail_dn)
trail_dn_x := trail_dn == low ? n : trail_dn_x

//Set btm extension label/line
if barstate.islast and show_hl_swings
    line.set_xy1(extend_btm, trail_dn_x, trail_dn)
    line.set_xy2(extend_btm, n + 20, trail_dn)

    label.set_x(extend_btm_lbl, n + 20)
    label.set_y(extend_btm_lbl, trail_dn)
    label.set_text(extend_btm_lbl, trend > 0 ? 'Strong Low' : 'Weak Low')

//-----------------------------------------------------------------------------}
//Order Blocks Arrays
//-----------------------------------------------------------------------------{
var iob_top = array.new_float(0)
var iob_btm = array.new_float(0)
var iob_left = array.new_int(0)
var iob_type = array.new_int(0)

var ob_top = array.new_float(0)
var ob_btm = array.new_float(0)
var ob_left = array.new_int(0)
var ob_type = array.new_int(0)

//-----------------------------------------------------------------------------}
//Pivot High BOS/CHoCH
//-----------------------------------------------------------------------------{
//Filtering
var bull_concordant = true

if ifilter_confluence
    bull_concordant := high - math.max(close, open) > math.min(close, open - low)

//Detect internal bullish Structure
if ta.crossover(close, itop_y) and itop_cross and top_y != itop_y and bull_concordant
    bool choch = na

    if itrend < 0
        choch := true
        bull_ichoch_alert := true
    else
        bull_ibos_alert := true

    txt = choch ? 'CHoCH' : 'BOS'

    if show_internals
        if show_ibull == 'All' or (show_ibull == 'BOS' and not choch) or (show_ibull == 'CHoCH' and choch)
            display_Structure(itop_x, itop_y, txt, ibull_css, true, true, internal_structure_lbl_size)

    itop_cross := false
    itrend := 1

    //Internal Order Block
    if show_iob
        ob_coord(false, itop_x, iob_top, iob_btm, iob_left, iob_type)

//Detect bullish Structure
if ta.crossover(close, top_y) and top_cross
    bool choch = na

    if trend < 0
        choch := true
        bull_choch_alert := true
    else
        bull_bos_alert := true

    txt = choch ? 'CHoCH' : 'BOS'

    if show_Structure
        if show_bull == 'All' or (show_bull == 'BOS' and not choch) or (show_bull == 'CHoCH' and choch)
            display_Structure(top_x, top_y, txt, bull_css, false, true, swing_structure_lbl_size)

    //Order Block
    if show_ob
        ob_coord(false, top_x, ob_top, ob_btm, ob_left, ob_type)

    top_cross := false
    trend := 1

//-----------------------------------------------------------------------------}
//Pivot Low BOS/CHoCH
//-----------------------------------------------------------------------------{
var bear_concordant = true

if ifilter_confluence
    bear_concordant := high - math.max(close, open) < math.min(close, open - low)

//Detect internal bearish Structure
if ta.crossunder(close, ibtm_y) and ibtm_cross and btm_y != ibtm_y and bear_concordant
    bool choch = false

    if itrend > 0
        choch := true
        bear_ichoch_alert := true
    else
        bear_ibos_alert := true

    txt = choch ? 'CHoCH' : 'BOS'

    if show_internals
        if show_ibear == 'All' or (show_ibear == 'BOS' and not choch) or (show_ibear == 'CHoCH' and choch)
            display_Structure(ibtm_x, ibtm_y, txt, ibear_css, true, false, internal_structure_lbl_size)

    ibtm_cross := false
    itrend := -1

    //Internal Order Block
    if show_iob
        ob_coord(true, ibtm_x, iob_top, iob_btm, iob_left, iob_type)

//Detect bearish Structure
if ta.crossunder(close, btm_y) and btm_cross
    bool choch = na

    if trend > 0
        choch := true
        bear_choch_alert := true
    else
        bear_bos_alert := true

    txt = choch ? 'CHoCH' : 'BOS'

    if show_Structure
        if show_bear == 'All' or (show_bear == 'BOS' and not choch) or (show_bear == 'CHoCH' and choch)
            display_Structure(btm_x, btm_y, txt, bear_css, false, false, swing_structure_lbl_size)

    //Order Block
    if show_ob
        ob_coord(true, btm_x, ob_top, ob_btm, ob_left, ob_type)

    btm_cross := false
    trend := -1

//-----------------------------------------------------------------------------}
//Order Blocks
//-----------------------------------------------------------------------------{
//Set order blocks
var iob_boxes = array.new_box(0)
var ob_boxes = array.new_box(0)

//Delete internal order blocks box coordinates if top/bottom is broken
for element in iob_type
    index = array.indexof(iob_type, element)

    if close < array.get(iob_btm, index) and element == 1
        array.remove(iob_top, index)
        array.remove(iob_btm, index)
        array.remove(iob_left, index)
        array.remove(iob_type, index)
        bull_iob_break := true

    else if close > array.get(iob_top, index) and element == -1
        array.remove(iob_top, index)
        array.remove(iob_btm, index)
        array.remove(iob_left, index)
        array.remove(iob_type, index)
        bear_iob_break := true

//Delete internal order blocks box coordinates if top/bottom is broken
for element in ob_type
    index = array.indexof(ob_type, element)

    if close < array.get(ob_btm, index) and element == 1
        array.remove(ob_top, index)
        array.remove(ob_btm, index)
        array.remove(ob_left, index)
        array.remove(ob_type, index)
        bull_ob_break := true

    else if close > array.get(ob_top, index) and element == -1
        array.remove(ob_top, index)
        array.remove(ob_btm, index)
        array.remove(ob_left, index)
        array.remove(ob_type, index)
        bear_ob_break := true

iob_size = array.size(iob_type)
ob_size = array.size(ob_type)

if barstate.isfirst
    if show_iob
        for i = 0 to iob_showlast-1
            array.push(iob_boxes, box.new(na,na,na,na, xloc = xloc.bar_time))
    if show_ob
        for i = 0 to ob_showlast-1
            array.push(ob_boxes, box.new(na,na,na,na, xloc = xloc.bar_time))

if iob_size > 0
    if barstate.islast
        display_ob(iob_boxes, iob_top, iob_btm, iob_left, iob_type, iob_showlast, false, iob_size)

if ob_size > 0
    if barstate.islast
        display_ob(ob_boxes, ob_top, ob_btm, ob_left, ob_type, ob_showlast, true, ob_size)

//-----------------------------------------------------------------------------}
//EQH/EQL
//-----------------------------------------------------------------------------{
var eq_prev_top = 0.
var eq_top_x = 0

var eq_prev_btm = 0.
var eq_btm_x = 0

if show_eq
    eq_top = ta.pivothigh(eq_len, eq_len)
    eq_btm = ta.pivotlow(eq_len, eq_len)

    if eq_top
        max = math.max(eq_top, eq_prev_top)
        min = math.min(eq_top, eq_prev_top)

        if max < min + atr * eq_threshold
            eqh_line = line.new(eq_top_x, eq_prev_top, n-eq_len, eq_top
              , color = bear_css
              , style = line.style_dotted)

            eqh_lbl = label.new(int(math.avg(n-eq_len, eq_top_x)), eq_top, 'EQH'
              , color = #00000000
              , textcolor = bear_css
              , style = label.style_label_down
              , size = eqhl_lbl_size)

            if mode == 'Present'
                line.delete(eqh_line[1])
                label.delete(eqh_lbl[1])

            eqh_alert := true

        eq_prev_top := eq_top
        eq_top_x := n-eq_len

    if eq_btm
        max = math.max(eq_btm, eq_prev_btm)
        min = math.min(eq_btm, eq_prev_btm)

        if min > max - atr * eq_threshold
            eql_line = line.new(eq_btm_x, eq_prev_btm, n-eq_len, eq_btm
              , color = bull_css
              , style = line.style_dotted)

            eql_lbl = label.new(int(math.avg(n-eq_len, eq_btm_x)), eq_btm, 'EQL'
              , color = #00000000
              , textcolor = bull_css
              , style = label.style_label_up
              , size = eqhl_lbl_size)

            eql_alert := true

            if mode == 'Present'
                line.delete(eql_line[1])
                label.delete(eql_lbl[1])

        eq_prev_btm := eq_btm
        eq_btm_x := n-eq_len

//-----------------------------------------------------------------------------}
//Fair Value Gaps
//-----------------------------------------------------------------------------{
var bullish_fvg_max = array.new_box(0)
var bullish_fvg_min = array.new_box(0)

var bearish_fvg_max = array.new_box(0)
var bearish_fvg_min = array.new_box(0)

float bullish_fvg_avg = na
float bearish_fvg_avg = na

bullish_fvg_cnd = false
bearish_fvg_cnd = false

[src_c1, src_o1, src_h, src_l, src_h2, src_l2] =
  request.security(syminfo.tickerid, fvg_tf, get_ohlc())

if show_fvg
    delta_per = (src_c1 - src_o1) / src_o1 * 100

    change_tf = timeframe.change(fvg_tf)

    threshold = fvg_auto ? ta.cum(math.abs(change_tf ? delta_per : 0)) / n * 2
      : 0

    //FVG conditions
    bullish_fvg_cnd := src_l > src_h2
      and src_c1 > src_h2
      and delta_per > threshold
      and change_tf

    bearish_fvg_cnd := src_h < src_l2
      and src_c1 < src_l2
      and -delta_per > threshold
      and change_tf

    //FVG Areas
    if bullish_fvg_cnd
        array.unshift(bullish_fvg_max, box.new(n-1, src_l, n + fvg_extend, math.avg(src_l, src_h2)
          , border_color = bull_fvg_css
          , bgcolor = bull_fvg_css))

        array.unshift(bullish_fvg_min, box.new(n-1, math.avg(src_l, src_h2), n + fvg_extend, src_h2
          , border_color = bull_fvg_css
          , bgcolor = bull_fvg_css))

    if bearish_fvg_cnd
        array.unshift(bearish_fvg_max, box.new(n-1, src_h, n + fvg_extend, math.avg(src_h, src_l2)
          , border_color = bear_fvg_css
          , bgcolor = bear_fvg_css))

        array.unshift(bearish_fvg_min, box.new(n-1, math.avg(src_h, src_l2), n + fvg_extend, src_l2
          , border_color = bear_fvg_css
          , bgcolor = bear_fvg_css))

    for bx in bullish_fvg_min
        if low < box.get_bottom(bx)
            box.delete(bx)
            box.delete(array.get(bullish_fvg_max, array.indexof(bullish_fvg_min, bx)))

    for bx in bearish_fvg_max
        if high > box.get_top(bx)
            box.delete(bx)
            box.delete(array.get(bearish_fvg_min, array.indexof(bearish_fvg_max, bx)))

//-----------------------------------------------------------------------------}
//Previous day/week high/lows
//-----------------------------------------------------------------------------{
//Daily high/low
[pdh, pdl] = request.security(syminfo.tickerid, 'D', hl()
  , lookahead = barmerge.lookahead_on)

//Weekly high/low
[pwh, pwl] = request.security(syminfo.tickerid, 'W', hl()
  , lookahead = barmerge.lookahead_on)

//Monthly high/low
[pmh, pml] = request.security(syminfo.tickerid, 'M', hl()
  , lookahead = barmerge.lookahead_on)

//Display Daily
if show_pdhl
    phl(pdh, pdl, 'D', pdhl_css)

//Display Weekly
if show_pwhl
    phl(pwh, pwl, 'W', pwhl_css)

//Display Monthly
if show_pmhl
    phl(pmh, pml, 'M', pmhl_css)

//-----------------------------------------------------------------------------}
//Premium/Discount/Equilibrium zones
//-----------------------------------------------------------------------------{
var premium = box.new(na, na, na, na
  , bgcolor = color.new(premium_css, 80)
  , border_color = na)

var premium_lbl = label.new(na, na
  , text = 'Premium'
  , color = TRANSP_CSS
  , textcolor = premium_css
  , style = label.style_label_down
  , size = size.small)

var eq = box.new(na, na, na, na
  , bgcolor = color.rgb(120, 123, 134, 80)
  , border_color = na)

var eq_lbl = label.new(na, na
  , text = 'Equilibrium'
  , color = TRANSP_CSS
  , textcolor = eq_css
  , style = label.style_label_left
  , size = size.small)

var discount = box.new(na, na, na, na
  , bgcolor = color.new(discount_css, 80)
  , border_color = na)

var discount_lbl = label.new(na, na
  , text = 'Discount'
  , color = TRANSP_CSS
  , textcolor = discount_css
  , style = label.style_label_up
  , size = size.small)

//Show Premium/Discount Areas
if barstate.islast and show_sd
    avg = math.avg(trail_up, trail_dn)

    box.set_lefttop(premium, math.max(top_x, btm_x), trail_up)
    box.set_rightbottom(premium, n, .95 * trail_up + .05 * trail_dn)

    label.set_xy(premium_lbl, int(math.avg(math.max(top_x, btm_x), n)), trail_up)

    box.set_lefttop(eq, math.max(top_x, btm_x), .525 * trail_up + .475*trail_dn)
    box.set_rightbottom(eq, n, .525 * trail_dn + .475 * trail_up)

    label.set_xy(eq_lbl, n, avg)

    box.set_lefttop(discount, math.max(top_x, btm_x), .95 * trail_dn + .05 * trail_up)
    box.set_rightbottom(discount, n, trail_dn)
    label.set_xy(discount_lbl, int(math.avg(math.max(top_x, btm_x), n)), trail_dn)

//-----------------------------------------------------------------------------}
//Trend
//-----------------------------------------------------------------------------{
var color trend_css = na

if show_trend
    if style == 'Colored'
        trend_css := itrend == 1 ? bull_css : bear_css
    else if style == 'Monochrome'
        trend_css := itrend == 1 ? #b2b5be : #5d606b

plotcandle(open, high, low, close
  , color = trend_css
  , wickcolor = trend_css
  , bordercolor = trend_css
  , editable = false)

//-----------------------------------------------------------------------------}
//Alerts
//-----------------------------------------------------------------------------{
//Internal Structure
alertcondition(bull_ibos_alert, 'Internal Bullish BOS', 'Internal Bullish BOS formed')
alertcondition(bull_ichoch_alert, 'Internal Bullish CHoCH', 'Internal Bullish CHoCH formed')

alertcondition(bear_ibos_alert, 'Internal Bearish BOS', 'Internal Bearish BOS formed')
alertcondition(bear_ichoch_alert, 'Internal Bearish CHoCH', 'Internal Bearish CHoCH formed')

//Swing Structure
alertcondition(bull_bos_alert, 'Bullish BOS', 'Internal Bullish BOS formed')
alertcondition(bull_choch_alert, 'Bullish CHoCH', 'Internal Bullish CHoCH formed')

alertcondition(bear_bos_alert, 'Bearish BOS', 'Bearish BOS formed')
alertcondition(bear_choch_alert, 'Bearish CHoCH', 'Bearish CHoCH formed')

//order Blocks
alertcondition(bull_iob_break, 'Bullish Internal OB Breakout', 'Price broke bullish internal OB')
alertcondition(bear_iob_break, 'Bearish Internal OB Breakout', 'Price broke bearish internal OB')

alertcondition(bull_ob_break, 'Bullish Swing OB Breakout', 'Price broke bullish swing OB')
alertcondition(bear_ob_break, 'Bearish Swing OB Breakout', 'Price broke bearish swing OB')

//EQH/EQL
alertcondition(eqh_alert, 'Equal Highs', 'Equal highs detected')
alertcondition(eql_alert, 'Equal Lows', 'Equal lows detected')

//FVG
alertcondition(bullish_fvg_cnd, 'Bullish FVG', 'Bullish FVG formed')
alertcondition(bearish_fvg_cnd, 'Bearish FVG', 'Bearish FVG formed')

//-----------------------------------------------------------------------------}
